[Dry goods sharing] How should the modular air conditioning unit be maintained?
The combined air conditioning unit is an air treatment equipment assembled from various air treatment functional sections.
Working principle of combined air conditioning unit
The fresh air enters the air conditioning unit and is mixed with the indoor return air in the mixing section. The mixed air passes through the primary filter section to filter out dust and debris, and then passes through the medium-efficiency filter section for secondary filtering to filter out smaller dust and debris. Then, cool down through the surface cooling section or heating section, or heat the air to reach the required temperature point, and then humidify through the humidification section to reach the specified air supply state point that the system needs humidity requirements, and finally pass through the fan section Send the treated air into the room.
Society is developing and human beings are progressing. As people's needs change, many industrial sites will use modular air conditioning units to improve the cleanliness, temperature and humidity of their sites, thereby creating a fresh, quiet and healthy working environment.
Such as the air purification system of various clean workshops, such as industrial electronics factory, precision machinery manufacturing factory, textile workshop, automobile spraying workshop, GMP pharmaceutical factory, cosmetics, food factory, pure water workshop, hospital surgery department, ICU, etc. occasion.
All machinery and equipment must be maintained after being used for a period of time, not to mention large items such as modular air-conditioning units.
Maintenance of combined air-conditioning unit
01
Maintenance of the core component surface cooler
The most representative core component in the internal structure of the combined air conditioning unit is the surface cooler, so it is very important to maintain the surface cooler properly.
Before using the combined air-conditioning unit in winter, open the exhaust valve at the lowest point of the surface cooler of the unit to drain the water remaining in the surface cooler during the summer cooling process, and use compressed air to dry it to avoid freezing water. The table cooler is damaged by freezing.
02
Filter cleaning
The filters in the unit should also be inspected regularly every week, and cleaned according to the inspection results. Take out the filter bag to beat or blow off the dust with compressed air (back blow), then wash it with detergent, and then rinse it with water for 2-3 times. After dehydration, place the filter bag to dry in a clean environment or in a drying room. Medium roasted.
03
Maintenance of other parts
Fan: Check the rotation of the fan weekly, check the tightness of the V-belt weekly, replace the belt every 6 months, 12 months or when it is severely worn, and check the bearings every six months, and refuel once a year.
Heat exchanger: According to the water quality, chemical cleaning agent is used to remove the scale of the pipeline every three years, and the surface of the heat exchanger is cleaned every two years.
Muffler: scrub once every six months.
Water humidifier: replace the filter material of the water filter regularly, and clean the water tank with disinfectant every week.
Electrical equipment: Carry out a safety inspection every six months to keep the grounding well to prevent vibrations from loosening the terminals or damaging the insulation layer by friction.
Others: The rust-prone parts of the air conditioning unit should be derusted and oiled once a year.
For modular air-conditioning unit equipment, only if we maintain it well, can the unit have high efficiency and be able to serve everyone better.
The daily maintenance of air-conditioning units is very important, and it is equally important for the selection of air-conditioning unit manufacturers! A professional and targeted solution manufacturer of air-conditioning units can allow you to get twice the result with half the effort in terms of time cost and investment cost!
Jiangsu Jincheng Air Conditioning Engineering Co., Ltd. is a professional manufacturer specializing in the design, production, installation and commissioning of air conditioning equipment in chemical fiber, real estate, textile, electronics, medicine, film, clean room and other industries.
Jincheng is committed to providing customers with innovative functions and excellent quality products. And the products adopt advanced design concepts and manufacturing processes, and meet the requirements of various related standards.
In the future development process of Jincheng Air Conditioning, we will provide users with high-quality products and superior services in line with the tenet of "quality first, reputation-based, and thoughtful service". Sincerely welcome domestic and foreign customers to come to our company for extensive and friendly cooperation.
